ASUS SBC Tinker board S RK3288 SoC 1.8GHz Quad Core CPU, 600MHz Mali-T764 GPU, 2GB LPDDR3 & 16GB eMMC TinkerboardS
 |
| ASUS SBC Tinker board S RK3288 SoC 1.8GHz Quad Core CPU, 600MHz Mali-T764 GPU, 2GB LPDDR3 & 16GB eMMC TinkerboardS |
| Name | Details |
|---|---|
| Buy now just | |
| Discount | |
| Product id | 32867529177 |
| Vendor | SmartFly Tech CO.,Ltd. |
| Category | Computer & Office - Demo Board & Accessories |
Description :
1x 10.1 inch LCD Touch Screen (Depend on your order)
1x 5V-3A Power Adapter --gift
1x 7inch Touch Screen (Depend on your order)
1x 8MP Camera Module (Depend on your order)
1x Acrylic Case (Depend on your order)
1x Heat Sink
1x Heat Sink ---gift
1x Metal Case (Depend on your order)
1x Micro USB Cable --gift
1x TF Card (Depend on your order)
1x Tinker Board S
1x Tinker Board S
A Debian-based distribution ensures a smooth and functional experience, directly out of the box. Whether it's browsing the web, watching videos, or writing scripts, TinkerOS is a great starting point for your next project or build.
Always Moving Forward with Makers
Better User Experience
Bundle 1:
Bundle 1： 2G LPDDR3+Heat Sink
Bundle 2： 2G LPDDR3+TF Card+Acrylic Case+Cooling Fan+Power Supply+Micro USB Cable+Heat Sink
Bundle 3： 2G LPDDR3+Metal Case+Cooling Fan+Power Supply+Micro USB Cable+Heat Sink+Screws
Bundle 4： 2G LPDDR3+TF Card+Metal Case+Cooling Fan+Power Supply+Micro USB Cable+Heat Sink+Screws
Bundle 5： 2G LPDDR3+8MP Camera Module+Power Supply+Micro USB Cable+Heat Sink
Bundle 6： 2G LPDDR3+10.1 inch touch Screen+Power Supply+Micro USB Cable+Heat Sink
Bundle2 & Bundle3 & Bundle4 & Bundle5 & Bundle6
Expert Support: firefly@ smartfire.cn Skype: smartfire_cn
Forum: https://tinkerboarding.co.uk/forum/
Further improving on key areas found lacking on many SBC boards, Tinker Board S is equipped with an HD codec that supports up to 24-bit/192kHz audio. Its integrated audio jack supports audio output and a microphone in, without an extension module. The audio jack also offers hassle-free plug-in detection so it automatically switches the audio output to an audio jack when the speaker or headset is connected.
Note：If you need European or American power, please leave a message.Thank you.
Official Intruction: https://www.asus.com/Single-Board-Computer/Tinker-Board-S/
One powerful feature of the Tinker Board S is the row of available GPIO (general purpose input/output) pins along the edge of the board. These pins are a physical interface between the Tinker Board S and the outside world. At the simplest level, you can think of them as switches that can be turned on or off. Of the 40 pins, 28 are GPIO pins (shared with SPI/UART/I2C pins). The Tinker Board S is equipped with one SPI bus that offers two chip selects. The SPI bus is available on the onboard 40-pin header.
Product Customization: firefly@ smartfire.cn
Recommend Accessories:
Software: https://tinkerboarding.co.uk/wiki/index.php?title=Software
Support & Service: https://www.asus.com/Single-Board-Computer/Tinker-Board-S/HelpDesk/
The Tinker Board S requires 5V/2~3A power via the micro-USB port. The exact amount of current (mA) the Tinker Board S requires will depend on what's connected to it. For general use, a 2A power supply from a reputable retailer will provide ample power to run your tinker board.Typically, Tinker Board S uses between 700 to 1000mA, depending on which peripherals are connected. It may use as little as 500mA when no peripherals are attached. Maximum power for the Tinker Board S is 1A. If you need to connect a USB device to bring power requirements above 0.5A, then you must connect to it via an externally powered USB hub.
Wiki: https://tinkerboarding.co.uk/wiki/index.php?title=Main_Page
[ Large Inventory ]
[ Official Sole Agnecy ]
1x Cooling Fan (Depend on your order)
Note：If you need European or American power, please leave a message.Thank you.
