ATSAMA5D36 MDKA5D36-EK_T70 development kit, 536MHz Cortex-A5, 256MB DDR2, image sensor, HS USB, ISI, Dual Ethernet, 6xUART, WIFI
 |
| ATSAMA5D36 MDKA5D36-EK_T70 development kit, 536MHz Cortex-A5, 256MB DDR2, image sensor, HS USB, ISI, Dual Ethernet, 6xUART, WIFI |
| Name | Details |
|---|---|
| Buy now just | |
| Discount | |
| Product id | 32222933957 |
| Vendor | Hangzhou Wild Chip Tech Co., Ltd. Store |
| Category | Computer & Office - Demo Board & Accessories |
Description :
The Atmel SAMA5D3 series is a high-performance, power-efficient embedded MPU based on the ARM® Cortex™-A5 processor, achieving 536 MHz with power consumption levels below 0.5 mW in low-power mode. The device features a floating point unit for high-precision computing and accelerated data processing, and a high data bandwidth architecture. It integrates advanced user interface and connectivity peripherals and security features. The SAMA5D3 series features an internal multi-layer bus architecture associated with 39 DMA channels to sustain the high bandwidth required by the processor and the high-speed peripherals. The device offers support for DDR2/LPDDR/LPDDR2 and MLC NAND Flash memory with 24-bit ECC. The comprehensive peripheral set includes an LCD controller with overlays for hardware-accelerated image composition, a touchscreen interface and a CMOS sensor interface. Connectivity peripherals include Gigabit EMAC with IEEE1588, 10/100 EMAC, multiple CAN, UART, SPI and I2C. With its secure boot mechanism, hardware accelerated engines for encryption (AES, TDES) and hash function (SHA), the SAMA5D3 ensures anti-cloning, code protection and secure external data transfers. CoreBoard: ATSAMA5D36, Cortex-A5, 536MHz 256MB DDR2 AT25 SPI FLASH(opt) 256MB NAND Flash (can upgrade to 1GB) 1.27 mm DIMM, 2x50x2+2x20 46x65mm 6layer PCB All GPIO on expansion Pin Mainboard: 2xSD 10/100M Ethernet 10/100/1000M Ethernet 7inch TFT LCD, 800x480 resolution with TouchScreen DBGU(RS232 level, DB9) RS232 UART 3xUART, TTL level 2xUSB HOST, 1xUSB OTG like(USB Device + USB Host) PCF8563T RTC AUDIO JTAG/SWD debug port LED ISI(Image Sensor Interface), include OV2640 image sensor SPI ADC 2xCAN USB WIFI LM75A temperature senso 1), bare machine programs(offered by ATMEL, IAR EWARM and GNU, no support) - adc_adc12 - dma - getting-started - pmc_clock_switching - ssc_dma_audio - twi_eeprom - twi_slave - sysc - adc_touchscreen - lcd - hdmi - fuse - spi_slave - tc_capture_waveform - usart_hw_handshaking - usart_spi - usart_synchronous - usart_serial - usart_iso7816 - usart_rs485 - pwm - periph_protect - hsmci_multimedia_card - hsmci_sdcard - hsmci_sdio - smc_nandflash - smc_norflash - spi_serialflash - emac - gmac - usb_audio_looprec - usb_audio_speaker - usb_cdc_serial - usb_core - usb_hid_aud - usb_hid_keyboard - usb_hid_mouse - usb_hid_msd - usb_hid_transfer - usb_iad_cdc_aud - usb_iad_cdc_hid - usb_iad_cdc_msd - usb_massstorage - usb_iad_cdc_cdc The software package includes the following libraries: - Libraires - libchip_SAMA5D3x - libboard_SAMA5D3x-ek - libnandflash - libpmecc - libsdmmc - libspiflash - libstoragemedia - usb 2) linux - U-boot source code - Linux 3.10.0 Drivers as follows: 10/100M Ethernet driver 10/100/1000M Ethernet driver USB Host driver USB Device driver LCD driver Touch screen driver USART driver Key button driver Nand Flash driver SPI driver TWI(I2C) driver On board sound card driver SD/MMC card driver CAN driver ISI image sensor driver, OV2640 included USB WIFI driver, USB WIFI included - offer virtual PC with all BSP - offer VFP toolchain - QT4.8.5, GUI, with demo 3) documents Datasheets Core board and main board schematic (PDF) User's manual MDKA5D36-EK, included 7" 800480 TFT LCD with TP OV2640 image sensor USB WIFI Power Adaptor USB cable*1, RS232 cable*1,RJ45 cable*2 DVD ROM looking for worldwide local agent pay pal acceptable before you press the order please go to DHL website to confirm if your location is belong to Remote Area,if so need another 30 USD for Remote Area Service.and we suggest that you contact us to confirm the shipping cost before press the order,maybe your location have a more discount
